I will pcb design for mechanical keyboards
PCB Design Engineer : We Deliver Clean, Optimized KiCad Layouts
Hi, I’m Ahsan, a professional PCB designer and Electronics Engineer. Two-time 🏆 PCBWay contest winner, I create schematics and production-ready PCB layouts with Gerber, BOM, CPL, KiCad files, and 3D ...
Nivel 1
Ha cumplido determinados criterios de rendimiento y muestra un gran potencial en la plataforma.
Acerca de este Servicio
Hi, If you need PCB Design for your Mechanical Keyboards with Hotswap Sockets, then this is the right gig.
I Will Create Schematic Circuit and PCB Design With Gerber, BOM, PDF, and Centroids Files For Your Custom Mechanical Keyboards ready for manufacturing and assembly.
What I Will Need From You:
A clear screenshot or image of your custom keyboard or layout created at KLE: http://www.keyboard-layout-editor.com. I will make the schematic circuit in PCB design software by myself according to your keyboard DXF.
Capabilities include:
- ESD Protection
- Type C with Daughterboard JST
- RGB or single color LEDs
- CherryMX with Hotswap Socket (If You Will Need)
- Bluetooth nrf52840, Wireless Support
- Integrated Atmega32u4/STM32 Microcontroller
- OLED, encoders (optional)
We Will Design Keyboard Styles:
- Numpad or Custom Style
- 40%, 60%, 65%, 80%Keyboard PCB
- Tenkeyless, WKL Keyboard PCB
- 96%, Full-Sized Keyboard PCB
- Split Keyboards
- Ergodox Keyboards
We will deliver professional PCB boards for your personal or business projects. Just click "Contact Me" button and discuss all your keyboard PCB requirements before placing the order.
Thank you!
Waiting For You Hi
#PCB #Keyboard #Mechanical #Design
Especialización:
Diseño de circuitos
•
Esquemas
•
Disposición
•
Huella
Formato de archivo:
Gerber
•
STEP
•
BRD
•
SCH
•
3DS
•
Software:
Altium Designer
•
Eagle CAD
•
EasyEDA
•
Fusion 360
•
KiCad
Mi porfolio
FAQ
I have KLE keyboard Layout ready, can we start the order?
Yes, I would only need your KLE layout. Just message me and we would start working on your keyboard PCB from today.
Did you send manufacturing and assembly files of Keyboard PCB?
Yes, you would receive Gerber, bom, picklace, kicad source files with finalized 3D step files ready for the manufacturing and assembly process for your keyboard PCB design. You can use JLCPCB or PCBWAY to assemble your PCBs easily.
I also need USB-C daughterboard PCB, can you do it?
Yes, I would provide you USB-C daughterboard PCB source files also. You can connect the daughterboard 4pin JST with the keyboard 4pin JST (Vcc, D-, D+, Gnd) to place the daughterboard TypeC connector at your desired position in the case.
I have only reference image of keyboard, is it work?
Yes, we can start working on your keyboard PCB design. I just need the layout image that shows exact cherry Mx switch locations.
My keyboard shape is custom, which package I need to select?
Message Me to discuss and I would send you the custom offer for your keyboard PCB style.
I need FR4 palte also.
Yes, I will also provide you gerbers for FR4 plate that you can order from JLCPCB easily in few clicks.
Which type of RGB Leds, you will use?
I would use sk6812-Mini-E RGB LEDs, which are reversible addressable, and gives light from the bottom hole in cherry Mx switches. The operating voltage would be 5V from TypeC.
My question is not in list.
Just Inbox Me with your question and then we can start working on your keyboard PCB.
